Dilation of 2D labelsSee full documentation

image =	dilateLabel2dImg (inLabImg)
image =	dilateLabel2dImg (inLabImg,mode)

Detailed Description

Dilate the labels in the input label image until filling all pixels.

This algorithm dilates the labels in the input image until the image contains no more background pixels.

It is also possible to ask to the algorithm an additional step to compute the separation lines.

Here is an example of label dilation

Example of Python code :

Example imports

import PyIPSDK
import PyIPSDK.IPSDKIPLAdvancedMorphology as advmorpho

Code Example

    # opening of input binary image
    inBinImg = PyIPSDK.loadTiffImageFile(inputImgPath)

    # Labelize the binary image
    labelImg = advmorpho.connectedComponent2dImg(inBinImg)

    # dilate the labels to have a basins image
    outBasinsImg = advmorpho.dilateLabel2dImg(labelImg)

    # dilate the labels to have separated basins
    outSplitImg = advmorpho.dilateLabel2dImg(labelImg, PyIPSDK.eDLM_Split)

Example of C++ code :

Example informations

Header file

#include <IPSDKIPL/IPSDKIPLAdvancedMorphology/Processor/DilateLabel2dImg/DilateLabel2dImg.h>

Code Example

        ImagePtr pOutImg = dilateLabel2dImg(pInLabelImg, mode);
